JEDEC JESD8-18A
- FBDIMM SPECIFICATION: HIGH SPEED DIFFERENTIAL PTP LINK AT 1.5 V
- standard by JEDEC Solid State Technology Association, 03/01/2008
- Category: JEDEC
$106.00
$53.00
This specification defines the high-speed differential point-to-point signaling link for FBDIMM, operating at the buffer supply voltage of 1.5V that is provided at the FBDIMM DIMM connector. This specification also applies to FBDIMM host chips which may operate with a different supply voltage. The link consists of a transmitter and a receiver and the interconnect in between them. The transmitter sends serialized bits into a lane and the receiver accepts the electrical signals of the serialized bits and transforms them into a serialized bit-stream. The first generation FBDIMM link is being specified to operate from 3.2 to 4.8 Gb/s. The specifications are defined for three distinct bit-rates of operation: 3.2 Gb/s, 4.0 Gb/s and 4.8 Gb/s.
PDF
All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.
Multi-User Access
After purchasing, you have the ability to assign each license to a specific user.
Printable
At any time, you are permitted to make printed copies for your and your members' reference use.
