• JEDEC J-STD-020D.01

JEDEC J-STD-020D.01

  • JOINT IPC/JEDEC STANDARD FOR MOISTURE/REFLOW SENSITIVITY CLASSIFICATION FOR NONHERMETIC SOLID STATE SURFACE-MOUNT DEVICES
  • standard by JEDEC Solid State Technology Association, 03/01/2008
  • Category: JEDEC

$62.00 $31.00

This document identifies the classification level of nonhermetic solid-state surface mount devices (SMDs) that are sensitive to moisture-induced stress. It is used to determine what classification level should be used for initial reliability qualification. Once identified, the SMDs can be properly packaged, stored and handled to avoid subsequent thermal and mechanical damage during the assembly solder reflow attachment and/or repair operation. This revision now covers components to be processed at higher temperatures for lead-free assembly.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
