JEDEC JESD75-1
- BALL GRID ARRAY PINOUTS STANDARDIZED FOR 16, 18, AND 20-BIT LOGIC FUNCTIONS USING A 54 BALL PACKAGE
- standard by JEDEC Solid State Technology Association, 10/01/2001
- Category: JEDEC
$48.00
$24.00
This standard establishes a 54 Ball Grid Array pinout for 16, 18 and 20-bit standard logic devices that are currently being produced in 48 and 56 Pin SSOP and TSSOP packages. The 54 Ball Grid Array Package is organized as a 6 x 9 array with balls on a .8mm x .8mm grid pitch.
