JEDEC JESD 77C
- TERMS, DEFINITIONS, AND LETTER SYMBOLS FOR DISCRETE SEMICONDUCTOR AND OPTOELECTRONIC DEVICES
- standard by JEDEC Solid State Technology Association, 10/01/2009
- Category: JEDEC
$228.00
$114.00
A revised and significantly expanded reference for technical writers and educators, manufacturers, buyers and users of discrete semiconductor and optoelectronic devices, is now available. Revision C of JEDEC Standard No. 77 includes extensive information on: letter symbol conventions; diodes and rectifiers (including signal, rectifier, microwave, tunnel and backward, voltage-regulator, voltage-reference, current regulator, and varactor diodes); transistors (including FETs, JFETs, and IGBTs); photosensitive devices, photoemitters, and optocouplers; thyristors and PUTs; and transient voltage suppressors. Terms and symbols, with their definitions, are arranged alphabetically by product type. Where applicable, graphical symbols are also included.
PDF
All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.
Multi-User Access
After purchasing, you have the ability to assign each license to a specific user.
Printable
At any time, you are permitted to make printed copies for your and your members' reference use.
