JEDEC JESD51-8
- INTEGRATED CIRCUIT THERMAL TEST METHOD ENVIRONMENTAL CONDITIONS - JUNCTION-TO-BOARD
- standard by JEDEC Solid State Technology Association, 10/01/1999
- Category: JEDEC
$56.00
$28.00
This specification should be used in conjunction with the overview document JESD51, Methodology for the Thermal Measurement of Component Packages (Single Semiconductor Device) [1] and the electrical test procedures described in JESD51-1, 'Integrated Circuit Thermal Measurement Method (Single Semiconductor Device' [2. The environmental conditions described in this document are specifically designed for testing of integrated circuit devices that are mounted on standard test boards with two internal copper planes [3]. This standard is not applicable to packages that have asymmetric heat flow paths to the printed board caused by such thermal enhancements as fused leads (leads connected to the die pad) or power style packages with the exposed heat slug on one side of the package.
PDF
All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.
Multi-User Access
After purchasing, you have the ability to assign each license to a specific user.
Printable
At any time, you are permitted to make printed copies for your and your members' reference use.
