• JEDEC JESD 209-2B

JEDEC JESD 209-2B

  • LOW POWER DOUBLE DATA RATE 2 (LPDDR2)
  • standard by JEDEC Solid State Technology Association, 02/01/2010
  • Category: JEDEC

$247.00 $124.00

This document defines LPDDR2, including features, functionalities, AC and DC characteristics, packages, and ball/signal assignments. This specification covers the following technologies: LPDDR2-S2A, LPDDR2-S2B, LPDDR2-S4A, LPDDR2-S4B, LPDDR2-N-A, and LPDDR2-N-B. The purpose of this specification is to define the minimum set of requirements for JEDEC compliant 64 Mb through 8 Gb for x8, x16, and x32 SDRAM devices as well as 64 Mb through 32 Gb for x8, x16, and x32 for NVM devices. Item 1725.01C.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
