IEEE C37.101-1985
- IEEE Guide for Generator Ground Protection
- standard by IEEE, 12/31/1984
- Category: IEEE
$47.00
$24.00
New IEEE Standard - Superseded.This guide has been prepared to aid in the application of relays and relaying schemes for the protection of synchronous generators for single-phase-to- ground faults in the stator winding.The guide is not intended for the selection of generator or ground connection schemes.The information included in the main body is limited to those generator connections, grounding practices, and protective schemes generally used in North America.Appendix A provides information on some of the protective schemes in use elsewhere in the world and on schemes which are not in wide-spread use throughout North America.Appendix B provides examples of how to calculate ground overcurrent and overvoltage relay settings for the various protective schemes (and how to coordinate them with voltage transformer secondary fuses.Appendix C is a bibliography of available literature on the ground-fault problem from which source material was drawn.Recommended protective schemes and the arrangements in which they may be applied are indicated in Table 1. The use of this table is described in Section 3 with supporting information provided in subsequent sections.
PDF
All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.
Multi-User Access
After purchasing, you have the ability to assign each license to a specific user.
Printable
At any time, you are permitted to make printed copies for your and your members' reference use.
