HI 9.6.2-2015

This standard includes recommendations for assessment of applied nozzle loads for the following pump types. When specified by the user, pumps supplied shall conform to these requirements.

• Horizontal end suction single stage (ANSI/ASME B73.1 and B73.3).
• Vertical in-line single stage (ANSI/ASME B73.2).
• Axially split one and two stage (BB1).
• Vertically suspended pump single casing discharge through column with diffuser and volute (VS1 and VS2).

Many other pump types are not included because of the different designs that are unique to each manufacturer. For pump types outside the scope of this standard, allowable nozzle loads should be established by the pump manufacturer, applied nozzle loads predicted by the purchaser, and differences, if any, negotiated and resolved by the two parties.

Details

Published:

05/15/2015

ISBN(s):

9781935762249

ANSI:

ANSI Approved

Number of Pages:

50

File Size:

1 file , 750 KB
