HI 7.1-7.5-2013

The 2013 version of this standard for Controlled Volume Metering Pumps is an updated and expanded version of the standard issued in 2006. These reciprocating positive displacement pumps are typically used for injecting chemical additives, proportional blending of multiple components, or the metered transfer of a single liquid. They are used in applications that require highly accurate, repeatable, and adjustable rate of flow. The applications can be categorized as one of the following:

• Single-point injection used for pH adjustment, boiler feed treatment, or process additive injection
• Controlled transfer used for reactor feed, point-to-point transfer, or filling operations
• Multi-stream proportioning, blending, and mixing, used for resin blending, mayonnaise production or continuous dye addition

This standard addresses specific nomenclature and definitions that are unique to metering positive displacement pumps, and provides cross-sections of designs such as:

• Mechanically coupled disc diaphragm
• Simple piston and plunger
• Hydraulic disc with contour plates
• Hydraulic disc with diaphragm positioning valve
• Hydraulic tubular diaphragm
• Hydraulic conical diaphragm

Controlled volume metering pumps are available with various drive configurations including:

• Electromagnetic drive
• Reciprocating air drive
• Fixed stroke-length drive
• Mechanical lost-motion drive
• Hydraulic lost-motion drive
• Variable stroke-length drive (non-lost motion)

Other topics of interest in this standard include:

• Storage
• Installation, piping, priming, alignment
• Lubrication requirements
• Operation
• Inspection and trouble locating

Details

Published:

2013

ISBN(s):

9781935762096

ANSI:

ANSI Approved

Number of Pages:

40

File Size:

1 file , 2 MB
