The basic welding symbol consists of the reference line, about which the weld symbol and dimensions are located, and an arrow designating the location for the weld. This chapter from the Welding Handbook, 9th Ed., Vol. 1, examines each component of the welding symbol reference line required arrow required tail basic weld symbol dimensions and other data finish symbols specification, process, or other references and supplementary symbols. It applies the welding symbols to common types of welds groove, fillet, plug, slot, spot, projection, seam, stud, and edge. Also covers brazed joints, soldering symbols and joints, and the elements of nondestructive examination symbols. Examples are in U.S. Customary units.
PDF
All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.
Multi-User Access
After purchasing, you have the ability to assign each license to a specific user.
Printable
At any time, you are permitted to make printed copies for your and your members' reference use.
